3.B - Manure Management
|NFR-Code||Name of Category||Method||AD||EF||State of reporting|
|3.B||Manure Management||see sub-category details|
|consisting of / including source categories|
|3.B.1.a & 3.B.1.b||Cattle||T3 (NH3 ), T2 (NOx , TSP, PM10 , PM2.5, NMVOC)||NS, RS||CS (NH3 , NOx ), D (TSP, PM10 , PM2.5 , NMVOC)||L: NH3 (for 3.B.1.a)|
|3.B.2, 3.B.4.d, 3.B.4.e||Sheep, Goats, Horses||T2 (NH3 , NOx , TSP, PM10 , PM2.5), T1 (NMVOC)||NS, RS||CS (NH3 ,NOx ), D (TSP, PM10 , PM2.5 , NMVOC)|
|3.B.3||Swine||T3 (NH3 ), T2 (NOx , TSP, PM10 , PM2.5), T1 (NMVOC)||NS, RS||CS (NH3 , NOx ), D (TSP, PM10 , PM2.5 , NMVOC)|
|3.B.4.a||Buffalo||NO, from 1990 until 1995, since 1996 IE, considered in 3.B.1.b|
|3.B.4.f||Mules and asses||IE, considered in 3.B.4.e|
|3.B.4.g i-iv||Poultry||T2 (NH3 , NOx , TSP, PM10 , PM2.5), T1 (NMVOC)||NS, RS||CS (NH3 , NOx ), D (TSP, PM10 , PM2.5 , NMVOC)||T: NH3 (for 3.B.4.g iii)|
In 2020, NH3 emissions from category 3.B (manure management) were 48.6 % from total agricultural emissions, which is equal to ~ 249.2 kt NH3. Within those emissions 52.0 % originate from cattle manure (~ 129.5 kt), 34.0 % from pig manure (ca. 84.7 kt), and 10.8 % from poultry manure (~ 27.0 kt). Calculations take into account the impact of anaerobic digestion of manure on the emissions.
NOx emissions from category 3.B (manure management) contribute only 1.3 % (~ 1.4 kt) to the total agricultural NOx emissions. They are calculated proportionally to N2O emissions, see Vos et al. (2022) 1).
NMVOC emissions from category 3.B (manure management) contributed 96.9 % (289.8 kt) from total agricultural NMVOC emissions (298.9 kt).
In 2020, manure management contributed, respectively, 71.3 % (43.0 kt), 42.8 % (12.9 kt) and 84.8 % (3.7 kt) to the total agricultural TSP, PM10 and PM2.5 emissions (TSP: 60.3 kt, PM10: 30.2 kt, PM2.5: 4.4 kt, respectively).
Activity data for all pollutants
The Federal Statistical Agency and the Statistical Agencies of the federal states carry out surveys in order to collect, along with other data, the head counts of animals. The results of these surveys are used for emission calculations, for details see Vos et al, 2022, Chapter 3.4.2.
The animal population figures used in the inventory are presented in Table 1. From 2017 to 2019 the animal population figures for horses, goats and poultry differ from the figures presented in the last IIR. In the last year’s submission these figures were extrapolated from the year 2016. Now there are new figures available for the year 2020 and the years 2017-2019 have been interpolated. Buffaloes are included in the cattle population figures, mules and asses are included in the horse population figures (IE), see Vos et al. (2022), Chapters 4.1 and 7.1. In the first years after the German reunification in 1990 animal livestock decreased markedly. The head counts for cattle continued to decrease significantly until 2006/2007, followed by a more or less stable period until 2014. Since 2015 a slight decrease occurred. In 2020, dairy cattle numbers are 61.7 % of 1990 numbers, while the total population of other cattle is at 56.2 % of 1990. Swine numbers decreased until 1995 and then increased slightly. Since 2014 a slight decrease occurred (2020: 81.6 % of 1990). The 2020 numbers of horses, sheep and goats are, respectively, at 90,8 %, 54.5 % and 172.1 % of 1990.
Figures for broilers and turkeys are showing a massive increase since 1990. Since the year 2013, there have been only minor changes of total poultry numbers. In total, 2020 poultry population figures are at 152.0 % of 1990. A detailed description of the animal numbers used can be found in the National Inventory Report 2022 2), Chapter 184.108.40.206.3.
Table 1: Population of animals
|Population of animals (in 1000)|
|mules and asses||IE||IE||IE||IE||IE||IE||IE||IE||IE||IE||IE||IE||IE||IE||IE|
|other animals: no data available a)|
Emission calculations in accordance with a Tier 2 or Tier 3 method require data on animal performance (animal weight, weight gain, milk yield, milk protein content, milk fat content, numbers of births, numbers of eggs and weights of eggs) and on the relevant feeding details (phase feeding, feed components, protein and energy content, digestibility and feed efficiency). To subdivide officially recorded total numbers of turkeys into roosters and hens, the respective population percentages need to be known. Details on data requirements for the modelling of emissions from livestock husbandry in the German inventory can be found in Voss et al. (2022), Chapters 4 to 8.
Most of the data mentioned above is not available from official statistics and was obtained from literature, from publications by agricultural associations, from regulations for agricultural consulting in Germany and from expert judgments. For 1991, 1995 and 1999, frequency distributions of feeding strategies, husbandry systems (shares of pasturing/stabling; shares of various housing methods), storage types as well as techniques of farm manure spreading were obtained with the help of the RAUMIS agricultural sector model (Regionalisiertes Agrar- und UmweltInformationsystem für Deutschland/ Regionalised agricultural and environmental information system for Germany). RAUMIS has been developed and is operated by the Institute of Rural Studies of the Thünen Institute (Federal Research Institute for Rural Areas, Forestry and Fisheries). For an introduction to RAUMIS see Weingarten (1995) 4); a detailed description is provided in Henrichsmeyer et al. (1996) 5).
RAUMIS did not model complete time series but only selected years. RAUMIS data for the years 1991, 1995, and 1999 are used in the inventory for years 1990 – 1993, 1994 – 1997, and 1998 – 1999, respectively. For the year 2010, respective data are used that were derived from the 2010 official agricultural census and the simultaneous survey of agricultural production methods (Landwirtschaftliche Zählung 2010, Statistisches Bundesamt/ Federal Statistical Office) as well as the 2011 survey on manure application practices (Erhebung über Wirtschaftsdüngerausbringung, Statistisches Bundesamt/ Federal Statistical Office).
For the year 2015, data on techniques of farm manure spreading from the 2016 official agricultural census (Agrarstrukturerhebung 2016, Statistisches Bundesamt / Federal Statistical Office) are used. The gaps between the latest RAUMIS model data (1999) and the first official data (2010) were closed by linear interpolation on district level. For the year 2020 data from the 2020 official agricultural census (Landwirtschaftszählung 2020) are used for housing systems, storage systems and manure spreading systems. For 2011 to 2019 the housing and storage systems data was linearly interpolated between the censuses of 2010 and 2020. The data on manure spreading techniques was linearly interpolated between the census data from 2010 and 2015, and for 2016 to 2019 between the censuses conducted in 2015 and 2020. In addition, it was taken into account that, as of 2012, slurry spread on bare soil has to be incorporated within four hours. For a description of the RAUMIS data, the data from official surveys and additional data from other sources see Vos et al. (2022), Chapter 3.4. Time series of frequency distributions of housing systems, storage systems and application techniques as well as the corresponding emission factors are provided in NIR 2022, Chapter 19.3.2.
NH₃ and NOₓ
N in manure management
In order to determine NH3 and NOx emissions from manure management of a specific animal category, the individual N excretion rate must be known as well as, for NH3, the TAN content of the N excretions. Default excretion rates are provided by IPCC Guidelines and default TAN contents can be found in the EMEP Guidebook, 20196). However, the German agricultural emission inventory uses N mass balances to calculate the N excretions and the TAN contents of almost all reported animal categories to be reported. N mass balance calculations (see below) consider N intake with feed, N retention due to growth, N contained in milk and eggs, and N in offspring. Table 2 presents national means of N excretions and TAN contents. For methodological details and mass balance input data see Vos et al. (2022), Chapter 220.127.116.11 as well as Chapters 4 to 8.
Table 2: National means of N excretions and TAN contents
|mean N excretions in kg per animal place|
|mean TAN contents in %|
N mass flow and emission assessment
The calculation of the emissions of NH3, N2O, NOx and N2 from German animal husbandry is based on the so-called N mass flow approach (e. g. Dämmgen and Hutchings, 2008 7)). This approach differentiates between N excreted with faeces (organic nitrogen Norg, i. e. undigested feed N) and urine (total ammoniacal nitrogen TAN, i. e. fraction of feed N metabolized). The N flow within the manure management system is treated as depicted in the figure below. This method reconciles the requirements of both the Atmospheric Emission Inventory Guidebook for NH3 emissions (EMEP, 2019), and the IPCC guidelines for greenhouse gas emissions (IPCC (2006)8). Reidy et al. (2008),9), showed for several European countries (Germany, the Netherlands, Switzerland, United Kingdom) that their N-flow based inventory models yielded, in spite of national peculiarities, comparable results as long as standardised data sets for the input variables were used.
Not explicitly shown in the N mass flow scheme is air scrubbing in housing and anaerobic digestion of manure. These issues are separately described further below. Note that emissions from grazing and application are reported in sector 3.D.
General scheme of N flows in animal husbandry
m: mass from which emissions may occur. Narrow broken arrows: TAN (total ammoniacal nitrogen); narrow continuous arrows: organic N. The horizontal arrows denote the process of immobilisation in systems with bedding occurring in the house, and the process of mineralisation during storage, which occurs in any case. Broad arrows denote N-emissions assigned to manure management (Eyard NH3 emissions from yards; Ehouse NH3 emissions from house; Estorage NH3, N2O, NOx and N2 emissions from storage; Eapplic NH3 emissions during and after spreading; Egraz NH3, N2O, NOx and N2 emissions during and after grazing; Esoil N2O, NOx and N2 emissions from soil resulting from manure input).
The model allows tracing of the pathways of the two N fractions after excretion. The various locations where excretion may take place are considered. The partial mass flows down to the input to soil are represented. During storage Norg can be transformed into TAN and vice versa. Both, the way and the magnitude of such transformations may be influenced by manure treatment processes like, e. g., anaerobic digestion where a considerable fraction of Norg is mineralized to TAN. For details see Vos et al. (2022), Chapters 18.104.22.168 and 22.214.171.124. Wherever NH3 is emitted, its formation is related to the amount of the TAN present. N2O emissions are related to the total amount of N available (Norg + TAN). NOx emissions (i. e. NO emissions) are calculated proportionally to the N2O emissions, see section 'Emission factors'. Note that the N2O, NOx and N2 emissions from the various storage systems include the respective emissions from the related housing systems.
Air scrubber systems in swine and poultry housings
For pig and poultry production the inventory model considers the effect of air scrubbing. Data on frequencies of air scrubbing facilities and the removal efficiency are provided by KTBL (Kuratorium für Technik und Bauwesen in der Landwirtschaft / Association for Technology and Structures in Agriculture). The average removal efficiency of NH3 is 80 % for swine and 70 % for poultry, while for TSP and PM10 the rates are set to 90 % and for PM2.5 to 70 % for both animal categories. For swine two types of air scrubbers are distinguished: certified systems that remove both NH3 and particles, and non-certified systems that remove only particles.
According to the KTBL data, 7.5 % of all pig places were equipped with certified systems in 2020, another 0.7 % were equipped with non-certified systems. For poultry 0.6 % of all laying hen places and 1.8 % of all broiler places were equipped with air scrubbers that remove both NH3 and particles. The amounts of NH3-N removed by air scrubbing are completely added to the pools of total N and TAN for landspreading. For details see Vos et al. (2022), Chapter 126.96.36.199.3.
Anaerobic digestion of manure
According to IPCC (2006), anaerobic digestion of manure is treated like a particular storage type that, however, comprises three sub-compartments (pre-storage, fermenter and storage of digestates). For details see Vos et al. (2022), Chapters 188.8.131.52 and 184.108.40.206. The resulting digestates are considered as liquid. Two different types of digestates storage systems are considered: gastight storage and open tank. For open tanks formation of a natural crust because of co-fermentation with energy crops is taken into account. Furthermore, the modelling of anaerobic digestion and spreading of the digestates takes into account that the amount of TAN in the digestates is higher than in untreated slurry and that the frequencies of spreading techniques differ from those for untreated slurry.
NH3 and NO emissions occur from pre-storage of solid manure, from non-gastight storage of digestates and from land-spreading of digestates (NH3 emissions and NO emissions from landspreading of digested manure are reported in 3.Da.2.a). There are no such emissions from pre-storage of slurry, from the fermenter and from gastight storage of digestates. Note that NH3 and NO emissions calculated with respect to the digestion of animal manures do not comprise the contributions by co-digested energy crops. The latter are dealt with separately in 3.D.a.2.c and 3.I.
Application of the N mass flow approach requires detailed emission factors for NH3, N2O, NOx and N2 describing the emissions from the various housing and storage systems.
The detailed NH3 emission factors are, in general, related to the amount of TAN available at the various stages of the N flow chain. The emission factors for laying hens, broilers, pullets, ducks and turkeys are related to N. Most NH3 emission factors are country-specific but some are taken from EMEP (2019). No specific NH3 emission factors are known for the application of digested manure. However, due to co-fermentation with energy crops, the viscosity of digested manure resembles that of untreated cattle slurry. Hence, the emission factors for untreated cattle slurry are adopted for the application of digested manure. For the detailed emission factors of livestock husbandry see Vos et al. (2022), Chapters 4 to 8; for emission factors of digested manure see Vos et al. (2022), Chapter 220.127.116.11.4. Table 3 provides, by animal category, the implied NH3 emission factors for manure management (housing and storage). The overall German NH3 IEF for manure application is reported in section 3.D.a.2.a.
The detailed emission factors for N2O, NOx and N2 relate to the amount of N available which is N excreted plus, in case of solid manure systems, N input with bedding material. The N2O emission factors are taken from IPCC (2006). The emission factors for NOx and N2 are approximated as being proportional to the N2O emission factors, i.e. the NO-N and N2 emission factors are, respectively, one-tenth and three times the value of the N2O-N emission factor, see Vos et al. (2022), chapter 18.104.22.168.5. This proportionality is also applied to anaerobic digestion of manure, where N2O emissions occur from pre-storage of solid manure and non-gastight storage of digestates with the emission factors being those used for normal storage of solid manure and the storage of untreated slurry with natural crust provided by IPCC (2006). Note that the inventory model calculates NO rather than NOx. The conversion of NO emissions into NOx emissions is achieved by multiplying the NO emissions with the NO2/ NO molar weight ratio of 46/30. This relationship also holds for NO and NOx emission factors.
Table 3 shows the implied emission factors of NH3 and NOx for the various animal categories. These emission factors normalize emissions from an animal category as the ratio of the total emission to the respective number of animals.
Table 3: IEF for NH3 & NOx from manure management
|IEF in kg NH₃ per animal place|
|IEF in kg NOₓ per animal place|
Trend discussion for Key Sources
Dairy cattle, other cattle and swine are key sources of NH3 emissions from manure management. The time series of the total NH3 emissions from all three categories are predominantly driven by the development of the animal numbers, see Table 1. However, the effect of decreasing animal numbers is partly compensated by the continuously increasing animal performance. This leads to increasing N excretions per animal, see Table 2, which, in principle, is reflected by increasing implied emission factors, see Table 3. For swine, as of 2012, the IEF is almost constant over time due to the use of air scrubbing systems that, to a high degree, remove NH3 from the housings.
For NOx there are no key categories.
All time series of the emission inventory have completely been recalculated since 1990. Tables REC-1 and REC-2 compare the recalculated time series for NH3 and NOx from 3B with the respective data of last year’s submission. The total emissions of NH3 slightly higher than those of submission 2021. The emissions from cattle are higher than in last year’s submission mainly due to the incorporation of new housing data from the 2020 agricultural census. The extent of cattle housing in tied systems, which has a lower NH3 emission factor than loose housing, has decreased in the last years. The NH3 emissions from swine and poultry are lower than in the 2021 submission due to the use of new data on raw protein content in fattening pig and broiler feed. See main page of the agricultural sector (Chapter 5 - NFR 3 - Agriculture (OVERVIEW)), list of recalculation reasons, No. 1, 7, and 8.
The overall NH3 emissions of other animals increased for the years 2017-2019 due to newly available figures on animal numbers of sheep and horses, see recalculations reasons No. 1 (Chapter 5 - NFR 3 - Agriculture (OVERVIEW)), list of recalculation reasons, No. 1. Further details on recalculations are described in Vos et al. (2022), Chapter 3.5.2.
Tables REC-1 and REC-2: Comparison of the NH3 and NOx emissions of the submissions (SUB) 2021 and 2022
|NH₃ emissions from manure management, in Gg|
|NOₓ emissions from manure management, in Gg|
No improvements are planned at present.
In 2020, NMVOC emissions from manure management amount to 289.8 which is 96.9 % of total NMVOC emissions from the agricultural sector. 84.7 % originate from cattle, 4.8 % from pigs, and 9.4 % from poultry.
The Tier 2 methodology provided by EMEP (2019)-3B-28 was used to assess the NMVOC emissions from manure management for dairy cattle and other cattle. For all other animals the Tier 1 methodology (EMEP (2019)-3B-17) was used.
Animal numbers serve as activity data, see Table 1.
For the Tier 2 methodology applied to dairy cattle and other cattle the following data was used:
- gross feed intake in MJ per year, country specific data from the annual reporting of greenhouse gas emissions, see NIR 2022, Chapter 22.214.171.124,
- proportion xhouse of the year the animals spend in the livestock building: country specific data, being equal to 1 – xgraz with xgraz the proportion of the year spent on pasture, see NIR 2022, Chapter 19.3.2,
- FRACsilage: 1 as proposed by EMEP (2019)-3B-29, since silage feeding for cattle is considered dominant in Germany
- FRACsilage store: 0.25 as proposed by EMEP (2019)-3B-30 for European conditions
- EFNMVOC, silage_feeding, EFNMVOC, house, EFNMVOC, graz are taken from EMEP (2019)-3B-32, table 3.11 as 0.0002002, 0.0000353 and 0.0000069 kg NMVOC/MJ feed intake, respectively,
- EFNH₃,storage, EFNH₃,building and EFNH₃,application are taken from the NH3 reporting (see above and 3.D).
For all other animal categories the Tier 1 emission factors for NMVOC were used as provided in EMEP (2019)-3B-18, Table 3.4 : For horses the emission factors for feeding with silage was chosen, for all other animals the emission factors for feeding without silage. Due to missing country-specific emission factors or emission factors that do not correspond to the inventory’s animal categories, the emission factors provided in EMEP (2019)-3B-18, Table 3.4, were used to define specific emission factors for weaners, boars, lambs, ponies/light horses and pullets, see Vos et al. (2022), Chapter 126.96.36.199. The implied emission factors given in Table 4 relate the overall NMVOC emissions to the number of animals in each animal category. The IEFs for dairy cattle and other cattle are much higher than the EMEP Tier 1 EF, which are 17.937 kg NMVOC for dairy cattle and 8.902 kg NMVOC for other cattle. The only possible explanation for those huge differences is that the EMEP Tier 2 and Tier 1 methods are not consistent.
The IEFs for the other categories provided in Table 4 correspond to the EMEP Tier 1 emission factors, except for horses, sheep, swine and other poultry. These categories comprise subcategories with different emission factors so that their overall IEFs in Table 4 represent subpopulation-weighted national mean values. Note that other poultry in Germany includes not only geese and ducks but also pullets. For pullets no default EF is given in the EMEP guidebook (EMEP, 2019), hence the EF of broilers has been adopted (because of similar housing). This assumption significantly lowers the overall IEF of other poultry in Table 4 the IEFs are listed separately for each poultry category). The IEF of the sheep category is significantly lower than the EMEP Tier 1 emission factor, because for lambs the EF is assumed to be 40% lower compared to an adult sheep in accordance with the difference in N excretion between lambs and adult sheep.
Table 4: IEF for NMVOC from manure management
|IEF in kg NMVOC per animal place|
Trend discussion for Key Sources
Dairy cattle and other cattle are key sources of NMVOC emissions from manure management. The total NMVOC emissions from both animal categories strongly correlate with the animal numbers given in Table 1 (dairy cattle: R² = 0.887; other cattle: R² = 0.998).
All time series of the emission inventory have completely been recalculated since 1990. Table REC-3 compares the recalculated time series of the NMVOC emissions from 3.B with the respective data of last year’s submission. The recalculated total emissions are slightly lower in some years and skightly higher in other years. This is due to improved methodology for the suckler cows (recalculation reason 4, see main page of the agricultural sector).and the use of the data from the official agricultural census of 2020 (recalculation reason 1) which are changing the NH3 emissions that have impact to the Tier 2 methodology which is applied for cattle NMVOC emissions. For other animals there are differences back to the year 2017. These differences are caused by updated animal numbers (see above). Further details on recalculations are described in Vos et al. (2022), Chapter 3.5.2.
Table REC-3: Comparison of NMVOC emissions of the submissions (SUB) 2021 and 2022
|NMVOC emissions from manure management, in Gg|
No improvements are planned at present.
TSP, PM10 and PM2.5
In 2020, TSP emissions from manure management amount to 71.3 % of total emissions from the agricultural sector. Within the emissions from manure management 22.5 % originate from cattle, 39.5 % from pigs, and 37.4 % from poultry. 42.8 % of the PM10 emissions from the agricultural sector are caused by manure management, where 34.4 % originate from cattle, 19.1 % from pigs, and 45.6 % from poultry. PM2.5 emissions from the agricultural sector mostly originate from manure management (84.9 %), of which are 78.0 % from cattle, 3.0 % from pigs, and 17.5 % from poultry.
EMEP (2013-3B-26) provided a Tier 2 methodology. In the current Guidebook (EMEP, 2019), this methodology has been replaced by a Tier 1 methodology. However, EF for cattle derived with the EMEP 2013 Tier 2 methodology remained unchanged. Therfore, the EMEP 201310) methodology was kept for cattle. For swine the EMEP 2013 methodology was formally kept but the EMEP 2019 Tier 1 EF was used both for slurry and solid based manure management systems. The same was done with the EMEP 2016 EFs for laying hens (used for cages and perchery). In case the EMEP 2019 EFs are simply rounded EMEP 2013 EFs, the unrounded EMEP 2013 EFs were kept. The inventory considers air scrubber systems in swine and poultry husbandry. For animal places equipped with air scrubbing the emission factors are reduced according to the removal efficiency of the air scrubber systems (90 % for TSP and PM10, 70 % for PM2.5). For details see Vos et al. (2022), Chapter 188.8.131.52.3.
Animal numbers serve as activity data, see Table 1.
Tier 1 emission factors for TSP, PM10 and PM2.5 from livestock husbandry are provided in EMEP (2019-3B-19), Table 3.5 and 55, Table A1.7. For cattle the Tier 2 emission factors provided in EMEP (2013-3B-29), Table 3-11 were used, because they differentiate between slurry and solid manure systems and were also used to develop the EMEP 2019 Tier 1 emissions factors.
The implied emission factors given in Table 5 relate the overall TSP and PM emissions to the number of animals in each animal category. The Guidebook does not indicate whether EFs have considered the condensable component (with or without).
Table 5: IEF for TSP, PM10 & PM2.5 from manure management
|IEF in kg TSP per animal place|
|IEF in kg PM10 per animal place|
|IEF in kg PM2.5 per animal place|
Trend discussion for Key Sources
Swine and laying hens are key sources of TSP emissions from manure management. The total TSP emissions from swine mainly follow the animal numbers given in Table 1. However, due to air scrubbing and different emission factors of the different housing systems of the four swine subcategories (sows with piglets, weaners, fattening pigs, boars) and the varying population shares in those housing systems the R2 of the linear regression is lower than 1 (0.78). For laying hens and broilers, due to the low prevalence of air scrubbing systems. TSP emissions almost perfectly correlate with the animal numbers provided in Table 1 (R2 = 1).
Table REC-4 shows the effects of recalculations on emissions of particulate matter. Changes in the years 2000 through 2019 are a consequence of the use of the data of the official agricultural census 2020 as well as new animal population figures for the years 2017-2019 (recalculation reason 1, see main page of the agricultural sector). Further details on recalculations are described in Vos et al. (2022), Chapter 3.5.2.
Table REC-4: Comparison of particle emissions (TSP, PM10 & PM2.5) of the submissions (SUB) 2021 and 2022
|TSP, PM10, PM2.5 emissions from manure management, in Gg|
For pollutant-specific information on recalculated emission estimates for Base Year and 2019, please see the pollutant specific recalculation tables following chapter 8.1 - Recalculations.
No improvements are planned at present.
Details will be described in chapter 1.7.
